This compact recorder with a sleek-looking finish is great for first-time users. Its small size means you can use it at home or on the go, and it features a built-in microphone for clear sound and dual tape speed for desired flexibility.

DUAL TAPE SPEED. Record up to 180 uninterrupted minutes with MC-90 tape at 1.2cm/sec.	CUE AND REVIEW. Cue/Review makes for fast, easy message monitoring.
BUILT-IN MICROPHONE. Built-in microphone for recording anytime and anywhere.	BUILT-IN SPEAKER. Receive crystal-clear sound wherever your recording takes place.

Features and Benefits

Dual tape speeds give you up to three hours recording time on a 90-minute tape

Cue/Review makes for fast, easy message monitoring

Built-in microphone for recording anytime, anywhere

Built-in, dynamic speaker delivers crystal-clear sound

External jack provides easy connection for earphone

Quick review lets you listen to what has just been recorded

Package Contents

Pearlcorder S702

Instruction Manual

2 x AA Batteries

1 x XB60 Tape

Specifications

Drive System	Capstan drive
Tracks	2 tracks, 1 channel monophonic
Tape Speed	2.4 cm/ sec., 1.2 cm/ sec. switchable
Microphone Sensitivity	Continuous adjustment using volume knob
Recording Method	n/a
Voice Activation	n/a
Speaker	36 mm round-type dynamic internal speaker
Overall Frequency Response	400 ~ 4000 Hz at 2.4 cm/ sec. 400 ~ 3000 Hz at 1.2 cm/ sec.
Remote Jack	n/a
MIC Jack	n/a
Earphone Jack	2.5 mm diameter, impedance 8 ohms
Practical Max Output	150 mW at 2.4 cm/ sec.
Continuous Battery Duration Time	Recording time 17 hours (when alkaline manganese dry cell batteries are used by the Olypmus testing method)
Power Source	n/a
Battery	Two 1.5V AA batteries
External Power Supply	n/a
Dimensions	4.8 in. (H) x 2.3 in. (W) x 1.0 in. (D) (excluding maximum protrusions)
Weight	5.6 oz. / 160 g (including batteries)

^
